BALLUFF BNI PG3-508-0C5-Z015 (New)

[BNI00HL] BALLUFF BNI PG3-508-0C5-Z015 (new)

https://www.grupomi.com/web/image/product.template/725688/image_1920?unique=16cc76d
Distribuidor activo, Interfaz = Profinet, Puesta en marcha rápida (FSU) = Sí, Indicación = no, Tensión de servicio Ub = 18...30.2 VDC, Conexión (COM 1) = M12x1-Conector hembra, 4-polos, D-codificado, Conexión (COM 2) = M12x1-Conector hembra, 4-polos, D-codificado, Conexión (entrada de suministro de corriente) = 7/8"-Conector, 5-polos, Conexión (salida de suministro de corriente) = 7/8"-Conector hembra, 5-polos, Conexión enchufes = 8x M12x1-Conector hembra, 5-polos, A-codificado, Entradas digitales = 16x PNP, tipo 3, Salidas digitales = 16x PNP, Entradas/salidas configurables = Sí, Interface IIoT = REST API, MQTT, Corriente de salida máx. = 2 A, Corriente total US, sensor = 9.0 A, Corriente total UA, actuador = 9.0 A, Material de carcasa = Fundición a presión de cinc, niquelada, Dimensiones = 68 x 37.9 x 224 mm, Temperatura ambiente = -25...70 °C, Grado de protección = IP67, Interfaces adicionales = 8x IO-Link, Versión IO-Link = 1.1.3, Clase de puerto = Type A, Safety Hub Support = Sí
Brand/Manufacturer: BALLUFF
Status:
Activo

USD 552.73 (El precio NO incluye IVA) 552.73 USD

SOLICITAR TIEMPO ENTREGA

This combination does not exist.

Contact Us
MONTERREY
0.0
SALTILLO
0.0
0.0 available

Terms and Conditions
Garantía de 6 meses
Envío: 1-2 días laborales

Share

Active Distributor, Interface = Profinet, Quick Start (FSU) = Yes, Indication = no, Operating voltage Ub = 18...30.2 VDC, Connection (COM 1) = M12x1-Female connector, 4-pole, D-coded, Connection (COM 2) = M12x1-Female connector, 4-pole, D-coded, Connection (power supply input) = 7/8"-Connector, 5-pole, Connection (power supply output) = 7/8"-Female connector, 5-pole, Connection plugs = 8x M12x1-Female connector, 5-pole, A-coded, Digital inputs = 16x PNP, type 3, Digital outputs = 16x PNP, Configurable inputs/outputs = Yes, IIoT interface = REST API, MQTT, Max Output Current = 2 A, Total US Current, Sensor = 9.0 A, Total UA Current, Actuator = 9.0 A, Housing Material = Zinc Die Casting, Nickel Plated, Dimensions = 68 x 37.9 x 224 mm, Ambient temperature = -25...70 °C, Degree of protection = IP67, Additional interfaces = 8x IO-Link, IO-Link version = 1.1.3, Port class = Type A, Safety Hub Support = Yes
