[PGD100.K.S9.A.1.R.R.Y.U.H-.E9......SU.CF..M5] ABB (New) - ABB

K : Sensor Range = 200 and 4000 kPa (2 and 40 bar, 29 and 580 psi)
S9 : Maximum working pressure = Standard by design according to sensor range
A : Transducer diaphragm material = AISI 316L ss
1 : Transducer Fill Fluid = Silicone oil
R : Process Connection Material = Remote or direct mount seal
R : Process Connection Size = Remote or direct mount seal
Y : Bolts and Gaskets = None
U : Housing Material / Electrical Connection = AISI 316L ss - M16 x 1.5 female thread
H : Protocol/Output = HART / 4 to 20 mA (including Easy Set up)
E9 : Extended Performance = ± 0,10% extended Base accuracy
SU : Software Application = Calibration to specified measuring span (incl. calibration
record) and /or tag no. on additional tag plate
CF : Inspection Certificates = Inspection certificate EN 10204–3.1 of calibration (5-point)
M5 : Manuals = English
S26FE - S26FE EN diaphragm seal with fixed flange, manufactured using Taylorʼs All-
Welded technology
Modelo sensor: S26FE.H.N2.S.F.SM.1.B.C.S.N.N.N----> SR22054
Descripción:
H : Transmitter Side of Connection = High pressure side
N2 : Mounting Flange Rating / Size = PN 40 bar / DN 50
S : Mounting Flange Material = AISI 316L SSF
Extensions Length / Material = Flush
SM : Diaphragm Material = AISI 316L SS
1 : Seal Surface Finish = Serrated - Type B1
B : Capillary Protection = AISI 316L SS armour with PVC protective cover
C : Capillary Length = 2 m (7 ft)
S : Fill Fluid = Silicone oil PMX 200 10 cSt
N : Flushing Ring Hole / Thread = None
N : Flushing Ring Material = None
N : Flushing Ring Plug / Gasket = No plug / No gasket
SR22054 Feature definition: Wika seal with internal diaphragm mod. 990.26 DN25
PN10..40 Type B1 AISI 316L
