[UM33A-000-11] YOKOGAWA (new)

Digital Indicator with Alarms Manufacturer : Yokogawa Product No. : UM33A-000-11 Product type : Digital Indicator With Alarm Basic : 0 = Standard type Functions : 0 = None Open networks : 0 = None Display language : 1 = English(Default. Can be switched to other language by the setting.) Case colour : 1 = Black (Light charcoal gray) Material : Polycarbonate (Flame retardancy: UL94V-0) Number of inputs: 2 points Input type: No-voltage contact input or transistor contact input Number of outputs: Retransmission output; 1, shared with 15 V DC loop power supply Current output: 4 to 20 mA DC or 0 to 20 mA DC/ load resistance of 600 ? or less Contact type and number of outputs: Alarm-1 to -3 output: contact point 1a; 3 points (common is independent) Alarm-4 output: contact point 1c; 1 point External dimensions (cm): 9.6 (W) × 4.8 (H) × 6.5 (depth from the panel face) (Depth except the projection on the rear panel) Panel cutout dimensions (cm): 9.2 (W) × 4.5(H) Wiring: M3 screw terminal with square washer (for signal wiring and power wiring) Mounting attitude: Up to 30 degrees above the horizontal. No downward titling allowed. Weight : 0.5 Kg
